Features
• Three-stage charging optimizes battery performance
• Maximum charging current up to 45A/60A/80A/100A/120A
• Maximum efficiency up to 98%
• Integrated intelligent slot compatible with SNMP/MODBUS communication


Model | FL-SCCM4524 | FL-SCCM6048 | FL-SCCM8048 | FL-SCCM10048 | FL-SCCM12048 | |||||
Max PV Input Vol | 145V | 195V | ||||||||
System Vol | 12V/24V/48/(Auto dection) | |||||||||
Max battery Charge Current | 45A | 60A | 80A | 100A | 120A | |||||
PV Array MPPT Vol Range | 15V-130VDC/ 30-130VDC/ 60-130V | 15V-170V/ 30-170V/ 60-170V | ||||||||
Max PV Input Power(12V) | 625W | 825W | 1100W | 1375W | 1650W | |||||
Max PV Input Power(24V) | 1250W | 1650W | 2200W | 2750W | 3300W | |||||
Max PV Input Power(48V) | 2500W | 3300W | 4400W | 5500W | 6600W | |||||
Charge information | ||||||||||
Charging Curve | See image below this sheet | |||||||||
Charge Algorithm | 3-Step | |||||||||
Charging Stages | Bulk,Absorpotion,FloatBulk,Absorption,Float | |||||||||
Temperature Compensation Coefficient | -5mV/℃/Cell/(25℃ref) | |||||||||
Temperature Compensation Range | 0℃ to 50℃ | |||||||||
Temperature Compensation Set Points | Absoption, Float Absoption, Float | |||||||||
Charging Set Points | Absoption Stage, Float Stage | |||||||||
Flooded Battery | 14.6V/29.2V/58.4V | |||||||||
ARG/Gel Battery(Default) | 14.1V/28.2V/56.4V | |||||||||
Overcharge voltage | 15V/30V/60V | |||||||||
Overcharge restart voltage | 14.5V/29V/58V | |||||||||
Battery discharge voltage | 8.5V/17V/34V | |||||||||
Battery overdischarge voltage | 9V/18V/36V | |||||||||
Mechanical & Environment | ||||||||||
Size(H*W*D) | 283*160*105mm | 283*160*105 | 333*215*120mm | |||||||
Weight | 4.0KG | 5.1KG | 7.0KG | |||||||
Ambient Temperature Range | 0℃ to 50℃ | |||||||||
Storage Temperature Range | -40℃ TO 75℃ | |||||||||
Humidity | 0%-90%RH(No condensing) | |||||||||
Enclosure | IP31(indoor&vented) |

Step 1: Choose Mounting Location Install the Charge Controller in an upright position out of direct sunlight, high temperature, and water.
sufficient room to run wires and that there is sufficient room above and below the controller for air flow.
